Omega Series Rock Breaker
With Picxxel’s Omega Series No Conditions Are Too Tough For You. The Closely Lapped Tolerances Give You Sustainable Productivity And Out Performs Other Breaker In Its Class. The Vibration And Soundproof Housing Minimizes The Noise Level And Effectively Dampens Vibrations. Especially Omega Rock Breaker Designed With Advance Technology & High Quality Materials That Is Powerful & Durable Which Maximizes The Output In Cost Effective Price.With Picxxel’s Omega Series No Conditions Are Too Tough For You. The Closely Lapped Tolerances Give You Sustainable Productivity And Out Performs Other Breaker In Its Class. The Vibration And Soundproof Housing Minimizes The Noise Level And Effectively Dampens Vibrations. Especially Omega Rock Breaker Designed With Advance Technology & High Quality Materials That Is Powerful & Durable Which Maximizes The Output In Cost Effective Price.
OMEGA SERIES BREAKER’S FEATURES BENEFITS
Easy to Service–With fewer parts integrated into the design, servicing the rock breaker hydraulic hammer is both easy and less expensive
Low Operating Cost–High flow rates and low operating pressures minimize heat generation and hydraulic shock loading for smooth operation and maximum service life for both the carrier and rock breaker
Hardox Steel Plate–Robust Casing with Hardox Steel At Bottom Is Added Advantage To The Life Of Rock Breaker
Energy Recovery System–Energy Recovery System Automatically Utilizes the Piston Recoil Energy To Increase The Performance Without Any Additional Hydraulic Input
Noise Reduction Technology–Boxed housing keeps the noise levels down, essential in high density population areas
Optimize Production–Breaker-mounted manual high/low stroke selector valve optimizes power and speed, giving you options
Shock Absorbing Design– improved vibration dampening – full isolated power call premium quality urethane cushions and wear plates absorb shock and vibration resulting reduced wear
2 Year Factory Warranty & Local Parts and Service.
Omega Series Specifications
| Parameters | Model | 70X | 90X | 150X | 240X | 340X |
| Application Carrier | TON | 4-7 | 6-9 | 11-15 | 18-21 | 30-40 |
| Gross Weight | KG | 360 | 395 | 861 | 1670 | 2830 |
| Required Oil Flow | L/M | 40-70 | 50-70 | 50-90 | 80-110 | 120-240 |
| Operating Pressure | BAR | 110-140 | 120-150 | 150-170 | 160-180 | 170-190 |
| Impact Rate | BPM | 500-900 | 400-800 | 350-700 | 350-600 | 300-450 |
| Tool Diameter | MM | 68 | 75 | 100 | 140 | 155 |
| Impact Energy | KG-M | 70 | 92 | 214 | 363 | 663 |
